Description
The A32080-1 is a Brake Disconnect tool designed for flight dispatch operations, primarily used on Boeing aircraft models such as the 747 and 767 series.
Key Specifications:
Dimensions:
- Length: 76 mm
- Width/Diameter: 51 mm
- Height: 51 mm
- Mass: 0.5 kg
- Number of Parts: 1
Usage:
This tool is utilized to seal an inoperative hydraulic brake, allowing the aircraft to be dispatched with one of its brakes disabled. According to the 767 Dispatch Deviation Procedures Guide (document D6-30T002), the end cover and slide plug of the brake shuttle valve are removed, and the A32080-4 disconnect is inserted. The A32080-1 consists of an A32080-4 disconnect contained in a storage bag.
Aircraft Compatibility:
- Boeing 747 Series:
- 747-100
- 747-200
- 747-300
- 747-400
- 747-8
